Universal mounting system for circuit breakers, terminal blocks, and industrial control equipment. Manufactured from high-quality cold rolled steel or aluminum, our DIN rails comply with IEC/EN 60715 standards. Available in slotted or unslotted designs with zinc plating for superior corrosion resistance.
The backbone of any electrical cabinet. Our DIN rails are precisely roll-formed to ensure a tight and secure fit for all standard DIN-rail mountable components (MCBs, relays, PLCs). The RoHS-compliant zinc plating ensures longevity even in humid environments.
TS35 type rail compatible with all major brands of breakers and terminal blocks.
Yellow or White Zinc plating provides excellent rust protection (up to 72h salt spray).
Available in 1.0mm and 1.5mm thickness for mounting heavy industrial components.
Standard 1m/2m lengths, or pre-cut to your specific cabinet dimensions.
Technical parameters for DIN Rails.
| Standard | IEC / EN 60715 (TS35/7.5 & TS35/15) |
|---|---|
| Material | Cold Rolled Steel (Q235) or Aluminum Alloy |
| Dimensions (W x H) | 35mm x 7.5mm / 35mm x 15mm |
| Thickness | 0.9mm / 1.0mm / 1.2mm / 1.5mm |
| Surface Treatment | White Zinc / Yellow Zinc / Trivalent Chromate (RoHS) |
| Perforation (Slotted) | 6.2 x 15mm / 5.2 x 25mm (Custom hole patterns available) |
| Length | 1 Meter / 2 Meters (Custom cutting service) |
| Applications | Mounting MCBs, Contactors, Relays, Terminal Blocks, PLCs |
Essential components for every electrical panel.
Organizing relays, timers, and control gear in industrial automation cabinets.
Securely mounting MCBs and RCDs for residential and commercial power distribution.
Used with terminal blocks to create neat and accessible wiring connection points.
Feedback on our Electrical Accessories.
"The tolerances are perfect. Breakers snap on firmly but are easy to remove when needed. Good steel quality."
"We buy the 2-meter lengths. They arrive straight without bending, which is rare for shipping long items."
"The slots are clean cut with no burrs. Makes installation much faster as we don't have to drill holes."
"Jinway's aluminum rails are lightweight yet strong enough for our PLC racks. Great for reducing cabinet weight."
"Consistent quality batch after batch. The plating thickness is good and passes our corrosion tests."
"Simple product but done right. The price is competitive and stock availability is always good."
Fill out the form to get a detailed proposal shortly. Direct from factory pricing.
